API 6D/BS 1868 Swing Check Valve

Key works: swing, check, valve, flange, bs1868, api6d, wcb

PRODUCT RANGE:

Sizes: NPS 2 to NPS24 (DN50 to DN600)

Pressure Range: Class 150 to Class 2500

End connection: RF, RTJ, BW

MATERIALS:

Casting (A216 WCB, WC6, WC9, A350 LCB, A351 CF8, CF8M, CF3, CF3M, A995 4A, A995 5A, A995 6A), Alloy 20, Monel, Inconel, Hastelloy

STANDARD

Design & manufacture API 6D, BS 1868
Face-to-face ASME B16.10, API 6D, DIN 3202
End Connection Flange Ends to ASME B16.5, ASME B16.47, MSS SP-44 (NPS 22 Only)
  - Socket Weld Ends to ASME B16.11
  - Butt Weld Ends to ASME B16.25
  - Screwed Ends to ANSI/ASME B1.20.1
Test & inspection API 598
Also available per NACE MR-0175, NACE MR-0103, ISO 15848
Other PMI, UT, RT, PT, MT

Design Features:

1.Small flow resistance for fluid;
2.Rapid opening and closing, sensitive action
3.With small close impact, not easy to product water hammer .
4.Equipped with counterweight, damper or gearbox is available as per customer request;
5.Soft sealing design can be chosen;
6.Can choose to lock the valve position in the fully open position
7.Jacketed design can be chosen.
8.Full or Reduced Bore
9.Bolted Cover or Pressure Seal Cover
10.Smooth fluid passageway and small fluid resistance;
11.Swing type disc.
